Fox Tank Company builds UL-142 gasoline storage tanks for commercial and industrial fuel storage. Available in horizontal and vertical configurations, these tanks are built for compliance, safe access, and long service life.
Tank Specifications
- UL-142 certified gasoline storage tanks
- Available in single-wall and double-wall designs
- Configurations include:
- Horizontal cylindrical
- Vertical cylindrical
- Rectangular box-type
- Dikes for open-top containment
- Standard sizes include:
- 4′ x 4′ = 325 gallons
- 4′ x 6′ = 525 gallons
- 4′ x 12′ = 1,050 gallons
- 6′ x 10′ = 2,100 gallons
- 6′ x 12′ = 2,500 gallons
- 8′ x 20′ = 7,500 gallons
- 8′ x 30′ = 11,250 gallons
- Custom options available, including:
- Horizontal tanks up to 11,000 gallons
- Vertical tanks up to 60,000 gallons
- Built from carbon steel
- Can be internally coated for improved corrosion resistance
- Double-wall tanks can include integrated leak monitoring
- Tanks are designed for safe access and proper venting
Compliance & Safety
- Built to UL-142 standards
- Supplied with features that support NFPA 30 compliance
- Double-wall options available
- Built for commercial and industrial fuel storage applications where safety and code compliance matter
Available Accessories
- Pumps: AC, DC, or rotary
- Spill containers
- Fill caps
- Normal vents
- Level gauges
- Leak detection gauges for double-wall tank
- Spill control systems
- Vents and monitoring setups
Request a Quote
Need a gasoline storage tank for a new installation or replacement project? Get in touch for pricing, available sizes, and help selecting the right UL-142 tank for your site.
